W-150
MODEL W-150
STYLE Baby Grand
SIZE 4’11″
FINISH
Polish Finish Ebony, White, Mahogany Red, Mahogany Brown, Walnut
Satin Finish Ebony
SPECIFICATIONS
Weber Grand Pianos were used at the turn of the century at the Metropolitan Opera because of their warm and rich tone. The pianos of today have the same quality features along with the new Del Fandrich designs.
Weber pianos use a lower tension scale along with the cold pressed hammers to give them a warm rich tone. The floating soundboard and direct coupled bass bridge enhances the bass response even in the smallest grands. Weber grands also feature AA Solid Spruce Soundboards.
Sizes W150 4’11 1/2, W152 5’2″, W175 5’9″, W185 6’1″.
MEASUREMENTS
LENGTH
4′ 11″
HEIGHT
3′ 4″
WIDTH
4′ 10″
WEIGHT
594 lbs
SOUNDBOARD AND RIBS
MATERIAL
AA SOLID SPRUCE
SOUNDBOARD AREA
1614.3 Sq. In.
NUMBER OF RIBS
11 CROWNED
BRIDGES
DESIGN
LAMINATED BASE/SOLID CAP
MATERIAL
BEECH/MAPLE
C0NSTRUCTION
HAND-PLANED, NOTCHED & PINNED
ACOUSTIC-CUT & TAPERED
ACOUSTIC-CUT & TAPERED
CASE
INNER
20 PLY
OUTER
12 PLY
BRACE MATERIAL
BIRCH OR BEECH
BRACE QUANTITIES
3
PLATE
PLATE CASTING
VACUUM PROCESSED CAST-IRON
DESIGN
YOUNG CHANG’S OWN DEL FANDRICH SCALE DESIGN
SCALE
DUPLEX/ALIQUOT DESIGN
1ST BASS STRING
42.5″
KEYBOARD
WHITE KEY SURFACE
ACRYLIC RESIN
BLACK KEY SURFACE
SATIN PHENOLIC RESIN
KEY MATERIAL
SPRUCE WITH MAPLE BUTTON
KEY FRAME MATERIAL
SPRUCE
DESIGN
WEIGHTED & BALANCED
HAMMERS
MOULDING
MAPLE
SHANK
MAPLE
FELT
JAPAN AMBIC FELT
WEIGHT
19 lb. T-STAPLED
ADDITIONAL FEATURES
ACTION
NORTH AMERICAN ROCK MAPLE
PINBLOCK
21 PLY HARD MAPLE
TUNING PINS
CHROME PLATED, ROLLED THREAD
PEDALS
3 SOLID BRASS WITH FULL SOSTENUTO
CASTERS
BRASS CASTERS
